PRANA 160 STANDARD

Productivity: 5/14/21/32/52/70;

Efficiency:up to 98%;

Noise at a distance of 3m: from 8 dB;

Heat exchanger material: сopper.

Diameter of the mounting hole: from 162 mm;

Length of the working module: from 450 mm;

Control: Remote control, Prana online application.

PRANA 160 – the most popular model in the PRANA assortment. The system is the basic solution for creating high-quality air exchange. The system is mounted up to 2 hours without disruption.

Features

The copper heat exchanger in PRANA Standard 150 recuperators provides preservation of up to 98% of heat and coolness. Separate heat exchanger ducts and a special design of the device prevent the mixing of supply and exhaust air flows.

Features for comfortable operation of the system in the cold season are provided.They prevent icing of the heat exchanger at temperatures below +4° C for the convenience of using the recuperator regardless of the season.

The capabilities of the system can be increased with the help of accessories. Filters clean the supply air from dust. Wind protection prevents blowing of the system and is recommended when installing the recuperator at a height of 4 floors and above. Painting the cover allows you to adapt the vent system to the room interior.

Functions:

• separate inflow and exhaust control;
• sleep Timer;
• remote control or application control;
• Bluetooth and Wi-Fi support;
• «Mini-heating» and «Winter mode».
• *BOOST mode is an unregulated mode, not recommended for continuous use.

PRANA 210C ERP

Productivity at every speed:6/25/35/48/90/140* m3/hr;

Efficiency: up to 92%;

Noise at a distance of 3m: from 8 dB;

Consumption: from 3.2 W;

Operating temperature range: -30...+40°C;

A set of sensors: Temperature, Atmospheric pressure, Humidity, VOC, CO2eq;

Mini-heating and anti-icing protection: yes;

Heat exchanger material: copper;

Diameter of the mounting hole: from 220 mm;

Length of the working module: from 490 mm;

Control: Remote control, Prana online application

Model description

PRANA 210C ERP PRO – maximum air exchange and smart features in one model. The ventilation system combines the advantages of the 200C series and the premium line in the brand’s assortment. The operation of the recuperator can be automated due to the sensors.

Features

The ERP PRO line opens up maximum opportunities for organizing high-quality air exchange. The model is equipped with air quality and state sensors. The recuperator monitors their indicators and accordingly adjusts the parameters of the system. At the same time, user participation is not required.

The 210C series complements these features with the maximum air exchange among domestic recuperators. The copper heat exchanger retains up to 92% of heat and coolness in the room. This allows you to reduce the costs of heating the premises in the cold season and the costs of air conditioning in hot seasons. In PRANA ECO ENERGY ventilation systems, the heating elements turn on automatically when the supply air temperature after recovery is below +14°C, and turn off automatically at +20°C.

If the supply air temperature after recovery is above +30°C, the «Winter mode» function is not available.

Functions

• all the advantages of the PRANA Standart and PRANA 210C ERP PRO;
•  carbon dioxide equivalent sensor;
• sensor of volatile organic compounds;
•  formation of air quality statistics (in the application when connected via Wi-Fi);
• fixation of air temperature at four points while going through the recuperator.
• *BOOST mode is an unregulated mode, not recommended for continuous use.

PRANA 210G ERP PRO

Productivity at every speed: 5/20/28/38/65/85* m3/hr;

Efficiency: Up to 97%;

Noise at a distance of 3m: from 8 dB;

Consumption: from 3.2 W;

Operating temperature range: -30...+40°C;

A set of sensors: Temperature, Atmospheric pressure, Humidity, VOC, CO2eq;

Mini-heating and anti-icing protection: Yes;

Heat exchanger material: Copper;

Diameter of the mounting hole: from 220 mm;

Length of the working module: from 440 mm;

Control: Remote control, Prana online application.

 PRANA PRANA 210G ERP PRO – a maximum of smart features and data. Comprehensive information on air quality and system performance, supplemented with an efficiency of up to 97%.

Features

The main feature of the ERP PRO line is that it is equipped with the largest number of sensors. With them, the ventilation system takes into account even more information about air quality when working in automatic modes. Thanks to the TVOC and CO2eq sensors, the recuperator reacts to an increase in the level of carbon dioxide and volatile organic compounds.

These advantages are complemented by the specifics of the PRANA 200G model. The ventilation system is equipped with a heat exchanger of a larger diameter, due to which the heat exchange area increases. Because of this, the model has a high recovery efficiency of up to 97%. In PRANA 210G ERP ventilation systems, the heating elements turn on automatically when the supply air temperature after recovery is below +14°C, and turn off automatically at +20°C.
If the supply air temperature after recovery is above +30°C, the «Winter mode» function is not available.

Functions

• all system features from the PRANA Standart and ERP series;
• air quality statistics in the application (when connected via Wi-Fi);
• CO2eq sensor (carbon dioxide equivalent level);
• TVOC sensor (records the proportion of volatile organic compounds in the air);
• statistics of changes in air quality (in the application when connected via Wi-Fi);
• information about the air temperature at 4 points of movement through the system.

PRANA 160 ERP PRO

Productivity at every speed: 5/14/21/32/52/70* m3/hr;

Efficiency: up to 98%;

Noise at a distance of 3m: from 8 dB;

Consumption: from 3.2 W;

Operating temperature range: -30...+40°C;

A set of sensors: Temperature, Atmospheric pressure, Humidity, VOC, CO2eq;

Mini-heating and anti-icing protection: yes;

Heat exchanger material: copper;

Diameter of the mounting hole: from 162 mm;

Length of the working module: from 450 mm;

Control: Remote control, Prana online application.

PRANA ERP PRO 160 is a model from the brand’s top line, designed for small spaces. Contains all the features of the previous two series. In addition, it provides a maximum of functions for monitoring and controlling the state and quality of air.

Features

The PRANA 160 ERP PRO series is the top of the line ERP series, which is equipped with three air temperature sensors and climate air quality sensors, namely CO2eq and TVOC, relative humidity and pressure.

Thanks to this, PRANA 160 ERP PRO recuperators automatically adapt the air exchange capacity in accordance with changes in the level of volatile organic compounds (TVOC), carbon dioxide (CO2eq) and relative humidity in the room.

TVOC is released when using perfumes, household chemicals, purchasing new furniture, and renovating.

The supply air temperature is recorded at two points: at the entrance to the system and at the supply to the room. The exhaust flow is recorded when the air is removed from the room.

 In PRANA ERP PRO ventilation systems, the heating elements turn on automatically when the supply air temperature after recovery is below +4°C, and turn off automatically at +8°C.

If the supply air temperature after recovery is higher than +18°C, the function is not available.

Functions:

• all functions of the PRANA Standart and PRANA ERP series;
•  carbon dioxide equivalent level sensor (CO2eq);
•  TVOC air quality sensor;
• informing about the level of system efficiency on the display and in the application;
• statistics of changes in air quality (in the application when connected via Wi-Fi);
• monitoring the temperature of supply and exhaust air before and after recuperation.

PRANA 210C ERP PRO

Productivity at every speed: 6/25/35/48/90/140* m3/hr;

Efficiency: up to 92%;

Noise at a distance of 3m: from 8 dB

Consumption: from 3.2 W

Operating temperature range: -30...+40°C

A set of sensors: Temperature, Atmospheric pressure, Humidity

Mini-heating and anti-icing protection: Yes

Heat exchanger material: copper

Diameter of the mounting hole: from 220 mm

Length of the working module: from 490 mm

Control: Remote control, Prana online application.

Model description

PRANA 210C ERP is the largest air exchange among the models in the line. The ventilation system offers increased supply and exhaust rates, complemented by smart features. There are automatic modes for high-quality air exchange in spacious rooms.

Features

The model is equipped with smart features of the ERP line, which automate the air exchange process, adapting it to indoor conditions, thanks to the relative humidity sensor, in particular. They allow the recuperator to independently record the change in the state of the internal air and adjust the supply and exhaust speeds accordingly.

Also, the recuperator contains features of the 200C series. Among them are increased air exchange rates and the minimum length of the working module from 490 mm. Like all household models, the system is installed in up to 2 hours. In PRANA ERP ventilation systems, the heating elements turn on automatically when the supply air temperature after recovery is below +14°C, and turn off automatically at +20°C.

If the supply air temperature after recovery is above +30°C, the «Winter mode» function is not available.

Functions

• all functions of the PRANA Standart series;
• a filter is provided as standard;
• informing about the status of the filter on the display and in the application;
• displaying time and date information on the display;
• air condition sensors: relative humidity and atmospheric pressure;
• automatic operating modes: AUTO and AUTO PLUS.
•
