SYF-8816N LED Lighthead

◆ Flash Pattern: 20 flash patterns

◆LED: 3W X 6

◆Voltage: DC 12V〜24 V

◆Peak Current: 1.0A (12V)

◆Average current: 0.5A (12V)

◆Size: 4.45" (113 mm) Length x1.12" (28.4mm) Width x0.39"(9.9 mm) Height

R65 Class 2 approval

SYF-88143 LED Lighthead

◆ Flash Pattern: 19 flash patterns
◆ LED: 3 W X 4
◆ Voltage: DC 12V〜24 V
◆ Peak Current: 1.4A (12V)
◆ Average current: 0.7A (12V)
◆ Size:4.65" (118 mm) Length x1.61" (41 mm) Width x1.14"(29 mm) Height

R65 Class 1approval

SYF-777W1/W2 LED Beacon

Plastic Base / Aluminum Base

◆ Size: Low Lens 6.4" (163 mm) DIA x 5" (126.9 mm) H
High Lens 6.4" (163 mm) DIA x 6.6" (167.6 mm) H
◆ Flash Patterns: Fifteen selectable "strobing" patterns
◆ Voltage: DC 12V〜24 V
◆ Max Current: 3.2A (12V)
◆ Average current: 1.2A (12V)
◆ Mounting: 1" pipe mounting thread in base
◆ Lens Material: Polycarbonate
◆ SAE J845 Class 1 approved SAE W3 - 1 11; Amber ECE R65 approved

SYF-8864 LED Lighthead

◆Flash Pattern: 20 flash patterns
◆LED: 3W X 4
◆Voltage: DC 12V〜24 V
◆Peak Current: 1.0A (12V)
◆Average current: 0.5A (12V)
◆Size: 1.05" (26.4 mm) Diameter x 1. 56”(39.4mm) Depth
IP68

R65 Class 1approval

SYF-88212 LED Lighthead Duo color

◆Flash Pattern: 11 flash patterns
◆LED: 3W X 12
◆Voltage: DC 12V〜24 V
◆Peak Current: 2.0 A (12V)
◆Average current: 1.0 A (12V)
◆Size: 4.7" (121 mm) Length x1.4" (36mm) Width x 0.4"(11.3 mm) Height

Meets R65 Class 2
