TURBO ARMEC DUAL STAGE DYNAMIC TURBO FLOW BENCH

Flowing your turbocharger and increase its performance.

Designed, Engineered, and Manufactured in Italy by TURBO ARMEC, STAGE 2 DUAL STAGE DYNAMIC TURBO ARMEC FLOW BENCH is easy to use for Turbo Precision Flowing with the same technical specifications dictated by every turbocharger manufacturer. TURBO CALIBRATION DURING FLOW.

STAGE 2 TURBO ARMEC FLOW BENCH fits very easily to every user's requirements.

Software and Hardware updates for FLOW D TURBO ARMEC FLOW BENCH are performed, via an internet connection.

FLOW D TURBO ARMEC FLOW BENCH is Industry 4.0 ready.

It is the first bench in the after-sales world that can test the dual-stage turbocharger simultaneously. It is very flexible because it controls up to 4 actuators in different combinations (for example 3 pneumatic (1 vacuum, 1 pressure, and 1 vacuum) and 1 electronic It has 2 inlet oil lines and 2 other lines for the out-of-oil, it measures the efficiency of the compressor wheel, by the output flow from compressor housing. Furthermore, this kind of bench allows truck turbochargers to flow because it has a special system that auto-detects what it is using. This bench checks reads, and reprograms the electronic actuator and the ETP tester.

Our main advantages are

1. Fast fitting by using quick magnetic couplings;

2. Maximum noise reduction;

3. Direct assistance from TURBO ARMEC;

4. Over 500 UNIQUE turbo codes;

5. Free Software updates;

6. Free Database updates;

7. FLOW “ON THE FLY” This feature allows you to read real values and make adjustments without repeating several tests. In this way, you will have the maximum working speed, with maximum precision.

8. Electric Controller Unit is provided by “SIEMENS”.

9. Pneumatic Line is provided by “FESTO”;

10. 270 lt tank of compressed air is required;1

1. A User-friendly interface with all the data that you need allows you to have a good work experience and use

Wide range of internal accessories

1 SET OF 51 IN ADAPTERS (20 Quick magnetic couplings and 31 flanges)

1 SET OF 26 OUT ADAPTER (13 Quick magnetic couplings and 13 flanges)

1 SET OF 16 OUT OIL ADAPTERS FOR THE FLOW BENCH

1 SET OF 11 IN OIL CONNECTION

1 SET OF 12 OUT COMPRESSOR FLOW ADAPTER + 1 FLOW + IN 21 ADAPTER

1 CENTESIMAL DIAL GAUGE KIT

1 CALIBRATOR 1 2 mt.

1-inch PIPE MF 1 SCREWED

1 INCH ADAPTER 1 UNIVERSAL HOLDER

1 T ADAPTER 1 SET O F 8 COMBINATION WRENCH – BETA 42

1 SET OF 3 HEXAGONAL T JEY WITH BALL – BETA 96 TBP

1 RUBBERISED MAGNET ø 45 X 9,5 1 TEMPERATURE SENSOR CAP

 TURBO ARMEC WST Water Seal Tester

The Best Technology at your service

WST can quickly test the water seal of the bearing housing and turbine housing of a turbocharger. It provides an accurate analysis of water losses due to possible damage to the aforementioned components. Easy to use, it will allow you to recognize and resolve recurring problems related to water consumption on the vehicle in total autonomy.

Equipped with the revolutionary ARMEC UNIVERSAL TURBO SUPPORT, it will allow an easy test through a simple and quick set-up of the turbo to be tested.
High reliability and simple maintainability make it an indispensable piece of equipment to guarantee a high-quality standard.
With a modern design, it is equipped with a 4.3" display for real-time viewing of all the necessary test information.

TURBO ARMEC DYNAMIC FLOW BENCH

Flowing your turbocharger and increase its performance.

Designed, Engineered, and Manufactured in Italy by TURBO ARMEC, FLOW D TURBO ARMEC FLOW BENCH is easy to use for Turbo Precision Flowing with the same technical specifications dictated by every turbocharger manufacturer. TURBO CALIBRATION DURING FLOW.

FLOW D TURBO ARMEC FLOW BENCH fits very easily to every user's requirements.

Software and Hardware updates for FLOW D TURBO ARMEC FLOW BENCH are performed, via an internet connection.

FLOW D TURBO ARMEC FLOW BENCH is Industry 4.0 ready.

Our main advantages are

1. Fast fitting by using quick magnetic couplings;

2. Maximum noise reduction;

3. Direct assistance from TURBO ARMEC;

4. Over 500 UNIQUE turbo codes;

5. Free Software updates;

6. Free Database updates;

7. FLOW “ON THE FLY” This feature allows you to read real values and make adjustments without repeating several tests. In this way, you will have the maximum working speed, with maximum precision.

8. Electric Controller Unit is provided by “SIEMENS”.

9. Pneumatic Line is provided by “FESTO”;

10. 270 lt tank of compressed air is required;1

1. A User-friendly interface with all the data that you need allows you to have a good work experience and simply use

Wide range of internal accessories

1 SET OF 51 IN ADAPTERS (20 Quick magnetic couplings and 31 flanges)

1 SET OF 26 OUT ADAPTER (13 Quick magnetic couplings and 13 flanges)

1 SET OF 16 OUT OIL ADAPTERS FOR THE FLOW BENCH

1 SET OF 11 IN OIL CONNECTION

1 SET OF 12 OUT COMPRESSOR FLOW ADAPTER + 1 FLOW + IN 21 ADAPTER

1 CENTESIMAL DIAL GAUGE KIT

1 CALIBRATOR 1 2 mt.

1-inch PIPE MF 1 SCREWED

1 INCH ADAPTER 1 UNIVERSAL HOLDER

1 T ADAPTER 1 SET O F 8 COMBINATION WRENCH – BETA 42

1 SET OF 3 HEXAGONAL T JEY WITH BALL – BETA 96 TBP

1 RUBBERISED MAGNET ø 45 X 9,5 1 TEMPERATURE SENSOR CAP

TURBO ARMEC ETP - TESTER and PROGRAMMER for ELECTRONIC ACTUATORS

Suits Your Needs

ETP can quickly test the electronic and electro-pneumatic actuators of the turbocharger.
It has been designed to diagnose and possibly repair the actuators on modern turbochargers.
Extensive and reliable functions, make the ETP tester the new reference point for Automotive professionals.

Versatility and Simplicity

Rugged design, matches intuitive data visualization thanks to the wide display, allowing you to overview important information for a complete diagnosis.
Its DATABASE allows users to obtain all necessary information for effective programming.
PWM and CAN-bus communications protocols go through dedicated cables, one for each type of actuator.

Double Functionality

The device allows control of the turbo VNT arm’s movement to check if it is fluid and solid; verify if all electronics and mechanical parts work properly, and manage internal DC motors that control arm movement.
Reads data on the electronic board and if necessary, writes a new data package to make it compatible with the market's major car manufacturers

Cables and Connectors

ETP is equipped with 28 cables with original connectors compatible with more than 730 turbochargers.
Hella, Siemens (VW/Audi), Mitsubishi, Sonceboz, Hitachi, Continental, Magneti Marelli, Mando, Kamtec, Mahle, Denso, and many more actuators makers are supported by ETP.
Discover more inside the complete list of cables, sorted by brand.

Operation Goes On Stage

ETP Tester can be successfully operated by professionals experienced in the remanufacturing of turbochargers and by any car technician, looking for a reliable partner to solve painful problems related to malfunctions of this delicate component.

Always Ready

Thanks to the practical case, you could take with you all the necessary tools for an optimal intervention.
Easy to transport, it safely carries your valuable equipment.
Through dedicated slots, your kit will always be well organized and ready to deploy.

VNT CONNECT Tester and Programmer for Electronic Actuator 12 V and 24 V with 2 Command Lines, Interlink System, 2 Universal Cables, and Carrying Case

VNT CONNECT is a modular tester, customizable from the base, and that grows according to your needs.

With an ergonomic design, it is equipped with a 12.3" display for real-time viewing of all the necessary test information.

The user starts from a base version of his choice, choosing one from Test Electronic Actuators from Light Vehicles, Program Electronic Actuators from Light Vehicles, Test Electronic Wastegates, or Test Electronic Actuators from Heavy Vehicles.

This feature alone makes this equipment the most complete on the market in this segment.

- Test Electronic Actuators From Light Vehicles’ Turbochargers

- Test Electronic Actuators From Heavy Vehicles’ Turbochargers

- Program Actuators From Light Vehicles’ Turbochargers

- Program Electronic Actuators From Heavy Vehicles (Holset)

- Test Electronic Wastegates

Thanks to the practical case, you could take with you all the necessary tools for an optimal intervention. Easy to transport, it safely carries your valuable equipment.

Through dedicated slots, your kit will always be well organized and ready to deploy.
